Repsol awards Europa Prefabri for the supply of portable cabins for its technical shutdown

/in , /by

Europa Prefabri has been awarded the bid for the supply of portacabin for the technical shutdown of the Industrial Complex of Repsol Petróleo in Puertollano (Ciudad Real) in 2018.

Europa Prefabri will provide Repsol with the necessary personnel and resources for the installation of eight 6.00 x 2.40 m portable cabins. The portable cabins are equipped with air conditioning with heat pump and will be used for dining facilities and offices at Repsol’s installations.

Works are scheduled to start in April this year. The portable cabins will be installed according to Repsol’s needs in each of the units that are operated on during the shutdown.

This year, Repsol shutdown will last 2 months and will allow the company to carry out inspection and maintenance works on more than a thousand units. With this shutdown, Repsol will also improve its energy efficiency. To this end, Europa Prefabri will provide portable offices equipped with furniture (office and meeting tables and chairs, filing cabinets, shelves, blackboards, litter bins, etc.), as well dining portable cabins, that come with a dining table and benches.

For events like this, our prefabricated portacabin are the ideal solution thanks to its fast assembly and space efficiency. The versatility of our portable cabins allows us to create spaces adapted to each project requirements, by its attachment in line or in height, quickly and easily.

In addition to offices and dining portacabin, we have all kinds of modules: sanitary modules, security portable cabins, advertising stands, prefabricated classrooms, warehouses, laboratories… We can also offer tailored solutions adapted to each client needs, by customizing the dimensions and design. We can place different equipment, doors and special windows, air conditioning and electrical systems, etc.

Companies like Repsol Petróleo opt for the use of portacabin for occasions such as their large multi-year shutdown, because our modules have been manufactured to offer simple assembly and disassembly. Indeed, the system is specially designed for temporary buildings, as is the case here.

Guard porta cabin for Bimbo in Azuqueca de Henares | Prefabri

/in , /by

Europa Prefabri Group has carried out a new project. In this case, we installed a guard porta cabin for Bimbo in Azuqueca de Henares.

Europa Prefabri is a group of companies with more than 30 years of experience in modular construction and in the manufacture of metal structures, such as parking canopies, grandstand roofs, pedestrian walkways or prefabricated warehouse metal structures.

[toc]

Technical specifications of the guard porta cabin for Bimbo

porta cabin Bimbo

Floor structure

The floor structure frame is formed by galvanized sheet profiles shaped in cold. There are OMEGA galvanized steel straps placed transversally achieving major stability supporting vibrations and heavy load. This floor structure supports up to 250 kg/m2 uniformly distributed.

  • 19mm thickness special anti-humidity phenolic plyboard floor
  • Finishing: sintasol Traviata 6026

Roof structure

The roof structure frame for this porta cabin is formed by longitudinal galvanized profiles and transversal straps conformed in cold. There are OMEGA galvanized steel straps placed transversally. These omegas support a trapezoidal sheet of 0.6mm thickness, screwed to the profiles through self-tapping screws with waterproof washers.

Columns

The columns are formed by galvanized sheet profiles shaped in cold. These columns are screwed to the floor and the roof of the porta cabin with special screws. There is a round PVC pipe with the diameter of 75mm serving as a gutter hidden in the interior of the column. A lacquered metal sheet in the interior of the module that fastens the electrical mechanisms, plugs, switches and electric protection panel covers the column.

Side walls

The lateral closure is composed of PUR 40mm thick insulating sandwich panels. Each panel consists of two lacquered galvanized steel sheets with a thermal and acoustic insulation layer in the middle formed by injected polyurethane self-extinguishing resins.

The panel is very resistant against humidity, staying unalterable over the years.

False ceiling

The false ceiling of the porta cabin is formed by galvanized and pre-lacquered metallic blades in white silicone polyester (0.5mm thickness). Fiberglass insulating material of 80mm thickness and vapour barrier is placed between the roof structure and the false ceiling.

The internal free height of this module is 2.275mm.

External carpentry

The external carpentry of the guard cabin is fabricated in white aluminium profiles.

The carpentry of this cabin is composed of:

  • Exterior door 975x2060mm with a handle and a lock
  • Glazed panel in white aluminium. Glass 3+3.

Internal carpentry

The internal carpentry is fabricated in aluminum profiles lacquered in white.

Electrical installation

The electrical installation of the guard porta cabin is complete except for the electrical line up to the location of the module.

All the electrical system and installations are adapted to the safety requirements of low voltage. Electrical supply is connected to the electrical box with an independent protection via magneto-thermal switches and switches necessary for lighting, emergency devices (if necessary), air conditioning and other uses. The box is protected against the direct and indirect contacts, overcurrent or short circuit.

  • Waterproof lights with diffuser 2x36W
  • Plug entries 16A+TT
  • Surface switches of 10A+TT

In the standard prefabricated modules the electrical wiring is concealed behind the false ceiling and the tops of the columns, so the whole electrical installation is completely hidden.

Finishing

  • The whole structure of the guard cabin was painted in white.
  • It has a surrounding roof structure in white sheet.

Others

In addition, we supplied an air conditioning system type split 2.250 BTU/hr.



Portable cabins rental: agreement with the Spanish Employment Agency of Madrid

/in /by



Europa Prefabri, a group of companies with more than 30 years of experience in the area of modular construction and design, manufacture and installing of parking canopies, has reached an agreement for the supply of portable cabins with the Official Employment Agency of Madrid’s Community. This is a two year-term contract and has a value of 300.000 euro.

Portable cabins rental: technical features

On the contract, the rental of the following prefabricated portable cabins models has been agreed:

Casetas prefabricadas en alquiler - modelo ana6000

  • Portable cabins 15m2 Model ANA 6000:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.

portable cabins

  • Portable cabins 20m2 Model ANA 8000:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.

Casetas prefabricadas en alquiler - modelo c2 1

  • Portable cabins with WC and office, 15m2 Model C-2:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.
    • Sink and WC.

    Casetas prefabricadas en alquiler - modelo c1 1

  • Prefabricated modules with 2 offices, 15m2 Model C-1:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.

Casetas prefabricadas en alquiler - modelo sn30p

  • Portable bathroom cabins, isolated, with showers and WC 15m2. Model SN30P:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.
    • Sink and WC.
    • Showers, water taps and electric boiler.

Casetas prefabricadas en alquiler - modelo SN6000

  • Portable isolated bathroom cabins with WC, 15m2. Model SN6000:
    • Thermal isolation.
    • With shutters and windows.
    • Electric installation for different uses and lighting.
    • Air conditioning winter/summer.
    • Sink and WC.

We will also supply isolated containers, with the following characteristics:

Casetas prefabricadas en alquiler - modelo LC10

  • 8 m2  containers with thermal isolation. Model LC10.

Casetas prefabricadas en alquiler - modelo LC120

  • 15 m2 containers with thermal isolation. Model LC120.

Europa Prefabri Group will also develop transportation, installation and maintenance of all the portable cabins rented.

NEW DISTRIBUTOR IN SENEGAL

/in , /by

Europa Prefabri keeps on working on its process of internationalization in Africa through a new distribution agreement in Senegal with a local company specialized in modular building.

Thanks to this new distributor, we are now present in one of the most stable countries in the region of  West Africa with great potential for economic growth.

The first order consists of several of the products we manufacture: prefabricated modules for offices, cabins and guard houses, car park shelters among others.



Prefabricated cabins for REPSOL

/in , /by

20 prefabricated modules assembled at REPSOL’s oil complex located in Puertollano, Ciudad Real.

Last december we get the contract to supply these special modular constructions installed in diferent places arround the complex.

Those are permanent  prefabricated cabins with structure fixed to the floor and glazed areas. Also has a complete WC inside.

Another example of many different uses for our modular constructions.





Portacabin to Peru

/in , /by

For the last few months we supplied 10 containers with flat pack modules to our distributor in Peru.

During january cabins have been assembled in the company’s plant near Lima.

There are now  being rented to differnt companies in this country.
